When the OpenClaw Gateway listens on loopback but operators, plugins, or automation still target the machine's LAN or tailnet hostname, you get a classic token plane skew: health checks succeed while authenticated RPC fails, or the service issues tokens its own callbacks cannot redeem. The failure chain often includes a mis-set gateway.auth stanza, aggressive restarts that trigger pairing storms, and self-referential traffic that surfaces token_missing while operator.read appears to stall. This runbook treats those symptoms as one coordinated incident: align bind addresses, issuers, and secrets, stabilise the process model, then close the ticket only after doctor, status, and Gateway probes agree. For credential collectors and mixed install surfaces that amplify auth drift, pair this guide with
OpenClaw SecretRef, audit streams, and doctor checks under mixed brew/npm/Docker installs.
For process isolation that keeps the Gateway away from container churn, see
OpenClaw --container / OPENCLAW_CONTAINER passthrough with a remote high-memory Gateway example.
1. Separate bind, audience, and issuer before touching tokens
Capture three explicit values in your ticket: the TCP bind (often 127.0.0.1), the hostname or URL every client uses, and the issuer metadata embedded in tokens. If probes hit http://127.0.0.1 while webhooks advertise https://gateway.internal, middleware may accept anonymous health traffic yet reject signed calls whose audience does not match. Run a one-line matrix — loopback-only, loopback plus reverse proxy, tailnet-only — and refuse to mix modes across environments. Snapshot openclaw.json and environment exports before edits so rollback is mechanical rather than tribal knowledge.
2. gateway.auth misconfiguration patterns that masquerade as "random 401s"
Teams frequently copy a hardened gateway.auth block from production into a laptop profile without trimming allowed origins, clock skew tolerance, or header names for local proxies. The Gateway then mints or validates tokens against the wrong secret rotation slot, or enforces HSTS-style assumptions on plain HTTP loopback. Diff the auth subtree against a known-good host class (daemon vs interactive) and collapse duplicate secret references — two paths pointing at different files produce alternating success and failure under load. After changes, restart once deliberately; repeated bounce windows are where pairing storms begin.
3. Restart pairing storms: slow the feedback loop
launchd ThrottleInterval, orchestrator crash loops, and external watchdogs can hammer the Gateway during partial boot — each restart clears in-memory ticket caches while upstreams still push traffic. Cap restart cadence, add a pre-flight status gate that waits for "listeners ready" before advertising readiness, and ensure dependent agents exponential-back off instead of fixed 200 ms loops. Log correlation should show paired spikes: process start, immediate TLS or auth failure, kill, repeat. Breaking that loop is prerequisite to trusting any subsequent token test.
4. token_missing on RPC self-call and operator.read stalls
When the Gateway issues an internal RPC to itself — metrics flush, policy fetch, or plugin bootstrap — it must reuse the same bearer surface as external callers. If the inner client strips Authorization or uses a stripped environment, you will see token_missing even though interactive curl works. operator.read gaps usually mean the control channel never acquired a lease: check file permissions on operator sockets, ensure the operator identity is included in the auth allow-list, and verify no sandbox profile blocks localhost egress. Treat self-RPC as a first-class path in your probe suite, not an afterthought.
- Inner and outer clients share one token source file or vault reference.
- Loopback calls include the same
Hostheader policy your public ingress enforces. - Operator lease logs show acquisition within one restart window, not only after manual intervention.
5. Cross-validation sequence: doctor, then status, then probes
Run doctor first to catch PATH skew, mixed Node installs, and stale plugin registrations that corrupt auth middleware loading. Follow with status to confirm listener bind order, advertised URLs, and secret hot-reload state. Only then execute scripted probes: localhost smoke, same-host loopback with forced headers, then tailnet or bastion paths. Archive raw JSON or structured logs for each step in the ticket — reviewers should see monotonic improvement, not cherry-picked successes. If any step disagrees, stop and bisect configuration before rotating tokens again; thrashing secrets extends outages without shrinking the blast radius.
6. Reproducible spillover: high-memory remote Mac, long agent inference
Picture a high-RAM remote Mac running a multi-hour agent job with large context windows: unified memory pressure spikes swap and slows TLS handshakes, so token refresh RPCs miss deadlines and the Gateway marks sessions stale while CPU is still "idle" in top. Operators interpret that as auth drift and restart repeatedly, amplifying pairing storms. Mitigation: pin the Gateway on a dedicated core budget with conservative connection timeouts, move the long inference workload to a second Mac or container host, and widen only the refresh path's deadline — not every anonymous route. Keep probes lightweight during inference peaks so they measure availability without becoming denial-of-service traffic themselves.
